BITVISUS

BIT VWC U1 116 Video Wall Controller

BIT VWC U1 116 Video Wall Controller

Regular price $1,299.00 USD
Regular price Sale price $1,299.00 USD
Sale Sold out
Request Quote

📣The price is the sample price, if you want to Get a Business cooperation price, please click the right corner button chat with us. You can also click here or click the Request Quote button to submit your request for a quote.

📌No need to set up, no stretching, no deformation, support hot-plugging, and power-off memory.

📌16 HDMI outputs support various display modes (4x4, 7x2, 2x7, 3x5, 5x3, 2x5, 5x2, 2x6, 6x2, 1x5, 1x7, etc)

📌Standard 1U chassis, output supports max. resolution is 7680x4320@60Hz. Multi-devices parallel use.

📌High-end programmable FPGA chip, full hardware real-time processing architecture, switching mode without delay.

📌Common application includes Conference system, Commercial display, Exhibition, Immersive room, Interactive projection, Digital Classroom, Live stream

Product Name BIT-MSE-U1-116
Input Signal 1*DP, 1*HDMI, 2*RJ45
Output Signal 16 HDMI
Input Max Pixel Clock Rate 600MHz
Output Max Pixel Clock Rate 300MHz
4x4 Max Support Resolution
7680x4320@60Hz
7x2/2x7 Max Support Resolution 3840x7560@60Hz, 13440x2160@60Hz
5x3/3x5 Max Support Resolution 5760x5400@30Hz, 9600x3240@30Hz
5x2/2x5 Max Support Resolution 3840x5400@60Hz, 9600x2160@60Hz
16x1 Max Support Resolution 1920x17280@60Hz
1x5 Max Support Resolution 9600x1080@60Hz
1x7 Max Support Resolution 13440x1080@60Hz
Hot Plugging
Power-off Memory
Support custom resolution
Size(L*W*H) 482.6mm*396.8mm*44mm
Weight 5kg
Power supply 12V@2A AC-DC
