BIT-Ex-HDBT-4K-KVM HDMI KVM HDBaseT Extender 150M Cat5/6 USB RS232 Transmitter Receiver HDCP 1.4

Name: BIT-Ex-HDBT-4K-KVM HDMI KVM HDBaseT Extender 150M Cat5/6 USB RS232 Transmitter Receiver HDCP 1.4
Brand: BITVISUS
SKU: BIT-Ex-HDBT-4K-KVM
Price: 195.0 USD
Availability: InStock

BIT-Ex-HDBT-4K-KVM HDMI KVM HDBaseT Extender 150M Cat5/6 USB RS232 Transmitter Receiver HDCP 1.4

$195.00 USD

Sale Sold out

Product variants

Quantity

Request Quote

Get a quote
Description
Specification

Get a quote

📣The price is the sample price, if you want to Get a Business cooperation price, please click the right corner button chat with us. You can also click here or click the Request Quote button to submit your request for a quote.

Description

📌Support Up to 4K30Hz 4K*2K Video Signal. HDbaseT : Long transmission distance, fast speed, no compression.

📌Extend up to 70 meters for 4K 30Hz resolution with Cat6 cable, up to 150 meters for 1080p resolution with Cat5e cable.

📌Stable and reliable performance. Support Power over Ethernet(POE)

📌Support USB KVM function. HDMI 1.4 & HDCP 1.4, HDMI audio output.

📌Support RS232, Plug & play setup without any software installation.

Specification

Product name	BIT-Ex-HDBT-4K-KVM
HDMI Protocol	HDMI 1.4
HDCP Protocol	HDCP 1.4
Max Pixel Clock Rate	330Mhz
Transmission Bandwidth	18Gpbs
Support Max. Resolution	4Kx2K@30Hz
Recommended HDMI Output/Input Distance	＜5m
Max. transmission distance	1080P: CAT5e 150m 4K@30Hz: CAT6a/CAT7 70m
Color Space	RGB 4:4:4
Operating Temperature	-5℃-70℃
Power	6W
Power Supply	12V@2A
Weight	600g
Size	135mm84.5mm26mm
