INDOOR DISPLAY 2x8 video wall SOLUTION



2x8 Indoor display Solution 15360*2160 video wall controller processor

By Bitvisus | October 26, 2022 |

Office Display Video Wall

In our office break rooms and aisles, sometimes it is necessary to have a display to brighten up our space

Making a large video wall is a great option, check out some great interior design solutions from around the world

7560x3840 Screen Rotation 90° 2x7 Vertical Screens Video Wall Solution
7560x3840 Screen Rotation 90° 2x7 Vertical Screens Video Wall Solution

2x8 indoor video wall in China

7560x3840 Screen Rotation 90° 2x7 Vertical Screens Video Wall Solution

The video wall can be very decorative in the office, making the space more vibrant and allowing our visitors to learn about our company through video while waiting in the lounge.

The office display wall solution from BITVISUS is used for the corporate culture wall, cycling the company's culture video, which has a powerful display effect in the limited space, thanks to the point-to-point 2X8 video wall, with a high resolution of 15360*2160, making the video images more impactful.

Video Wall Solutions:

Using 16 LCD displays spliced together into a desktop through the video wall controller processor BIT-MSE-U1-416, the final total pixels are up to 15360*2160 with no stretching and no distortion of the picture.

Device Requirements:

Graphics card: NVIDIA P2200

Input source computer system: Win8/Win10

Display: 18* 1920x1080 LCD screens

Video Wall Controller: BIT-MSE-U1-416

7560x3840 Screen Rotation 90° 2x7 Vertical Screens Video Wall Solution

Topology diagram

A PC with a P2200 graphics card was used as the input source, 16 1920*1080 LCD screens, and a video wall controller from Bitvisus, the BIT-MSE-U1-416. Due to the long distance of the input source, which exceeded our recommended connection distance, we recommended the use of our HDBT series network HDMI extenders with KVM, 16 HDMI extenders for 16 screens.

About BIT-MSE-U1-416

Bitvisus UHD Video Wall Controller Processor Resolution up tp 8Kx4K Commonly used in 3x5 5x3 2x7 7x2 3x4 4x3 4x4 3x3 Tv Display Wall solutions. Can also make special 1x16 16x1 1x5 1x7 etc. single row or single column video wall. 4 HDMI*2.0/DP 1.2 inputs, 16*HDMI 1.4 outputs. Applications: exhibition hall, indoor advertising, digital signage, commercial display, control room display, Immersive room, and interactive touch video wall & projection.

BIT-MSE-4K60-104PRO Product image

bIT-MSE-U1-416

Connection instruction and on-site video
